DTF Printer-A700#1
No limit on fabric materials
No need pre-coating
CMYK+ White (Fluorescent color for option)
2pcs EPSON i3200-A1 (4 heads for option)
Printing width: 60cm
Printing Speed: 10~15sqm/h
Software: Maintop/Photoprint/RIIN/CAD Link
DTF700 printer digital printing part machine Specification
|
SMT-DTF 2in1 PET film Printer |
2in1 PET film DTF printer-SPECIFICATION |
|
Max print size |
PET film printer max print size:70cm |
|
Print color,resolution |
4-8 Color (CMYK)+4W,DPI 1200/2400/3600 |
|
Power supply standard |
220V 50HZ/60HZ |
|
print mode |
4Pass 6Pass 8Pass 16sqr/h 13sqr/h 10sqr/h |
|
Power Rate |
Printer Set:230V Powder dryer set:2.4KW |
|
Heat Ironing temperature |
Heat 230。C;cold peel away film: 160-170。C |
|
print weight |
Max material weight 15-50KG |
|
Net / Gross Weight |
Printer set:130KG Powder dryer set:260KG |
|
Size ( L*W*H ) |
2in1 whole set :320*152*143CM |
|
Package ( L*W*H ) |
Printer set:168*75*68CM |
|
Print head daily maintainence |
Auto ink wipping,scraping ,moisturizing,cleaning system, |
|
NOTES: All height of plate can customize. |
Head :2-4 pcs4720/i3200 =CMYKCM+4W; |
Advantages
CMYK+ White (Fluorescent color for option)
Printhead: 2~4 PCS EPSON i3200-A1
Printing width: 60cm
Printing Speed: 10~15sqm/h (2heads), 18~23sqm/h
Software: Maintop/Photoprint
Ink type: Pigment Ink
If you want to make your favorite T-shirt, please contact us
Work Flow
How to finish a personal T-shirt
Application : cotton, polyester, linen, nylon, modal, etc
Other Accessories
If you need accessories, please contact us.
